Drilling Rigs And Equipment
Our drilling equipment has the capability of larger drilling rigs yet is much more manoeuvrable.
This allows for lower set up costs and better productivity. All our vehicles are fitted with winches and full recovery kits allowing for access to difficult sites.
- Incline / rollover tilt sensors
- Fully remote-control tracking and drilling operation
- Top hammer Geoprobe sampling
- Auto SPT
- Interlocked safety cage
- Reduced Operational Mode (ROM Mode)
- Firefighting, first aid and spill response equipment
- Double Hydraulic make and break clamps
- Powerful turbocharged engine performance
- In-situ data logger connectivity
- 2-speed variable-width caterpillar tracks
Dimensions
- Width – 780mm to 1.8m
- Length – 4.35m
- Travelling height with mast lowered – 2.2m
- Working height with mast and jib raised – 4.35
- Total weight 2.8 tonne
- Incline / rollover tilt sensors
- Remote control tracking operation
- Top hammer Geoprobe sampling
- Auto SPT
- Interlocked safety cage
- Reduced Operational Mode (ROM Mode)
- Firefighting, first aid and spill response equipment
- Double Hydraulic make and break clamps
- Powerful turbocharged engine performance
- 6-metre rod pull with option to reduce mast for confined spaces
- 2-speed variable-width caterpillar tracks
Dimensions
- Width – 1.4m to 1.7m
- Length – 5.2m to 7.5m
- Travelling height with mast lowered – 2.5m
- Working height with mast and jib raised – 7.5m
- Working height with mast raised and jib retracted – 5.2m
- Total weight – 5.8 tonne
Note: The rig can have the jib and tracks retracted to allow access to narrow entry and low roof heights
- Incline / rollover tilt sensors
- Fully remote-control tracking and drilling operation
- Top hammer Geoprobe sampling
- Auto SPT
- Interlocked safety cage
- Reduced Operational Mode (ROM Mode)
- Firefighting, first aid and spill response equipment
- Double Hydraulic make and break clamps
- Powerful turbocharged engine performance
- In-situ data logger connectivity
- 2-speed variable-width caterpillar tracks
Dimensions
- Width – 750mm to 1.3m
- Length – 4.3m
- Travelling height with mast lowered – 2.2m
- Working height with mast and jib raised – 4.3
- Working height with mast reduction – 2.3m
- Total weight – 3.4 tonne
Note: The rig can have the jib and tracks retracted to allow access to narrow entry and low roof heights
- Incline / rollover tilt sensors
- Remote control tracking
- Top hammer Geoprobe sampling
- Auto SPT
- Interlocked safety cage
- Reduced Operational Mode (ROM Mode)
- Firefighting, first aid and spill response equipment
- Double hydraulic make and break clamps
- Powerful turbocharged engine performance
- In-situ data logger connectivity
- 2-speed variable-width caterpillar tracks
Dimensions
- Width – 1.4m to 1.7m
- Length – 5.2m to 7.5m
- Travelling height with mast lowered – 2.5m
- Working height with mast and jib raised – 7.5m
- Working height with mast raised and jib retracted – 5.2m
- Total weight – 5.8 tonne
Note: The rig can have the jib and tracks retracted to allow access to narrow entry and low roof heights
- 6-metre rod pull
- Interlocked safety cage
- Auto SPT
- Hydraulic mast extension
- Double hydraulic make and break clamps
- Firefighting, first aid and spill response equipment
Dimensions
- Width – 2.3m
- Length – 6.8m
- Travelling height with mast lowered – 3.6m
- Working height with mast and jib raised – 7.1m
- Working height with mast raised, jib retracted and foot removed – 5.1m
- Total weight – 7.5 tonne
Note: The rig can have the jib retracted and foot removed to allow access to low roof heights
Water Cartage
Water can be transported to and around sites in water tanks which are integrated into the support vehicle chassis. This eliminates the potential for vehicle rollover. All staff are trained in the correct use of hydrants and fire plugs. Earthcore Drilling ensures current water permits are carried at all times during water cartage.
